- Allocation
→ Electronic Parts Catalogue
- Driver seat: heated seat cushion for front passenger seat -Z6-
- Front passenger seat: heated seat cushion for front passenger seat -Z8
- Allocation
→ Electronic Parts Catalogue
- Renew after removal
→ Chapter.
- Allocation
→ Electronic Parts Catalogue
- Driver seat: heated backrest for driver seat -Z7
- Front passenger seat: heated backrest for front passenger seat -Z9-.
- Allocation
→ Electronic Parts Catalogue
- Renew after removal
→ Chapter
Questions & answers
Assembly overview - seat heating element — Volkswagen Golf Mk7
What does the Golf Mk7 seat heating element assembly show?
Seat padding, heater element wiring, connector and mounting. If padding is renewed on a heated seat, the heating element must also be renewed.
1 -
Upholstery clip
For attaching backrest cover to backrest padding
Renew after removal
When installing, fit in same location using upholstery clip pliers
- ...
Special tools and workshop equipment
required
Removal wedge -3409
...
