Volkswagen Golf Mk7 Service & Repair Manual: Assembly overview - water drainage hoses
This assembly overview maps the Volkswagen Golf Mk7 sunroof drain hose routing: front and rear hoses on both sides, their connection points on the assembly frame, and the front and rear drain grommets.
| 1 - | Rear water drain hose |
- Left and right
- Cleaning → Chapter
- Removing and installing → Chapter
| 2 - | Front water drain hose |
- Left and right
- Cleaning → Chapter
- Removing and installing → Chapter
| 3 - | Connection |
- Qty. 4, part of assembly frame
| 4 - | Clip |
| 5 - | Rear drain grommet |
| 6 - | Front drain grommet |
Questions & answers
Assembly overview - water drainage hoses — Volkswagen Golf Mk7
Where do the Golf Mk7 sunroof drain hoses run?
Front hoses run down through the A-pillars and exit in the plenum chamber. Rear hoses run down through the C-pillars and exit behind the rear wheel arches.
How many sunroof drain hoses does the Golf Mk7 have?
Four: front left, front right, rear left and rear right. Each drains one corner of the sunroof frame channel.
