- For attaching backrest cover to backrest padding
- Renew after removal
- When installing, fit in same location using upholstery clip pliers
-V.A.G 1634
- Sewn to backrest cover
- Seats with through-loading function have a zip fastener instead of
beading strip
- Ensure it is properly seated
- Different equipment versions
- Allocation
→ Electronic Parts Catalogue
- Removing and installing backrest cover with backrest padding
→ Chapter
- Separating backrest cover from backrest padding
→ Chapter
- After installation, check that there are no creases in seat.
- For attaching backrest cover on rear backrest frame.
- Left and right
- Allocation
→ Electronic Parts Catalogue
- Removing and installing backrest cover with backrest padding
→ Chapter
- Separating backrest cover from backrest padding
→ Chapter
Questions & answers
Assembly overview - cover and padding for backrest — Volkswagen Golf Mk7
